S-DMX-DS41 Diseqc Switch 4-1

FTE UMS141 Diseqc Switch 4-1 LNB switch with 4 inputs

S-LNB-0.1DP

FTE eXcellento Single LNB 0.1db
LNC type: SINGLE
Input frequencies: Low Band: 10.7~11.7 GHz
High Band: 11.7~12.75 GHz
Number of outputs: 1
Output frequencies: Low Band: 950~1950 MHz / High Band: 1100~2150 MHz
Local oscillators: Low Band: 9.75 GHz
High Band: 10.60 GHz
Output impedance: 75 Ω
Conversion gain: 52 - 65 dB
Noise figure: 0.1 dB (Typ.)
Voltage supply: 13VDC-18VDC 0-22 KHz
Current consumption: 75 mA (Typical)
Community against UMTS/GSM/DECT interferers @~1,800 MHz: 40 dB min

TAL1420 Line Amplifier 4out 20db
FTE TAL1420UK Line Amplifier 4out 20db

AA20L Outputs: 2 Line Amplifier
EK AA20L Indoor House Amplifier 20dB
Type: Line Amplifier
Inputs: 1
Outputs: 2
Gain per output: 20db
Total Output: 104db

MANIA 818 FULL HD DVB-T2 MPG-4 RECEIVER

Golden Media Mania 818 HD DVB-T2 H.265 HEVC Receiver You tube LAN USB Multimedia

PSB2 MAXVIEW 1: 2 ANTENNA TV BOOSTER

PSB4 MAXVIEW 1:4 ANTENNA TV BOOSTER

PSB6 MAXVIEW 1:6 ANTENNA TV BOOSTER

ST834 COMPASS
Compass for travelers

R012W TV FEMALE MODULAR SOCKET

HANLIGHT R012W TV FEMALE Socket Outlet Modular(25X50mm)

R013W F CONNECTOR MODULAR SOCKET

Module F-Type MODULAR TV/Satellite Wall SOCKET Plate Inserts(25X60)

CSP4123 Two way Female-Male-Female

TV Aerial Splitter Silver
Two way screened coax splitter. Female-Male-Female

CSP144 WAY(1:4) SPLITTER
WAY(1:4) SPLITTER POWER PASS 5-2400Mhz

2UV/K MAST ANTENNA AMPLIFIER

MAST ANTENNA AMPLIFIER 2xUHF & 1xVHF
2UV/K MISTRAL MAST ANTENNA AMLIFIER

Ηigh gain amplifier.

Suitable for areas with low signal reception.

Accepts two UHF and one FM or VHF antennas.

The cables connections is made by terminals.

Specifications

VHF ιnput : FM, ch 2-4, 5-12, S11-S20 -2 dB gain.

This is an auxiliary input for modulators and radio.

UHF 1 ιnput : ch 21 - 60 Gain 10 - 32 dB adjustable.

UHF 2 input : ch 21 - 60 Gain 10 - 32 dB adjustable.

Output level : 107 dB / μV.

CSB4123A TV AERIAL SPLTTER male-Female-male

TV Aerial Splitter Silver
Two way screened coax splitter. male-Female-male

AT112 2-WAY SPLITTER

2-WAY SPLITTER POWER PASS 5-2400Mhz

GT-SP61 Splitter 1:6 5-2400mhz


6-WAY 1:6 SPLITTER POWER PASS 5-2400Mhz

AS039 LINE ANTENNA AMPLIFIER 1:2
TERRA ANTENNA LINE AMPLIFIER 1:2

Tεχνικά Χαρακτηριστικά:

Ενισχυτής 2 Εξόδων
Ενσωματωμένοι ρυθμιστές απολαβής
Απολαβή: 16dB/47MHz - 20dB/862MHz
Εύρος συχνοτήτων: 40-860MHz
Έξοδος: 100dBμV
Μέγιστη στάθμη εξόδου IMD3=60dB (DIN45004B) 100dBmkV
Ενσωματωμένο τροφοδοτικό

AS038 LINE ANTENNA AMPLIFIER 1:4

TERRA AS038 LINE ANTENNA AMPLIFIER

4 OUTPUT

Apartment amplifier 4 εξόδων
FREQ.RANGE:47-862MHZ
GAIN:20db
built-in adjustable gain regulators
die-cast housing inside plastic case

DMX-HDM1500 HDMI input Full HD Modulator
DigitMX DMX-HDM1500 DVB-T Full HD Modulator

DigitMX HDM1500 DVB-T Full HD modulator converts the HDMI signal from your audio video devices to RF signal for distribution to many TVs around your house or business

MOD-EDISION-LITE HDMI DOGITAL MODULATOR

MOD-SINGLE EDISION SINGLE -VBT HDMI DIGITAL MODULATOR

CSP13 1:3 ANTENNA SPLITTER

148.5500UK
FULL (16dB) output which can either be used for very long cable runs or via a signal splitter to feed up to 6 further points.

Separate inputs for VHF (Band III TV, FM and DAB digital radio) and UHF (Freeview, DVB-T and DVB-T2 HD digital TV)
Automatic line powering on the UHF input to power a masthead pre-amplifier for fringe reception areas or if you have a long cable run from aerial to amplifier

MDA121001 Analog Modulator with Display

EK MD-A Full Band Analog Modulator with Display
Type: Analog
Input Channels: Single
Output: 85db
RCA input: Yes
Display: Yes
Easy output channel programming through display
Full band (47 - 862 MHz)
Multistandard
High output level
L and R audio inputs
TV mix

TER3 FTE TER3 Splitter 1-3 (5-1000mhz)

FTE TER3 Splitter 1-3 (5-1000mhz)
Covered Band (MHz) 5-1000
Return band (MHz) 5-30 / 5-65
Nr. Of outputs 3
Distribution attenuation (dB) Freq.(MHz) Typ Max 5-300 5,4 5,9 300-606 5,5 6,0 606-1000 6,0 6,8
Decoupl. between outputs (dB) 5-300 > 35 300-606 > 25 606-1000 > 25
Return loss (dB) IN > 20 OUT > 20
Screening factor (dB) > 100
Impedance (Ω) 75
Current pass no
Connectors F female
Plastic support included
